T7P Specifications

• Card option
• IC card interface
• ISO 7816, EMV-certified
• Card reader
• Magnetic stripe
• Tracks 1, 2 standard; Track 3 optional
• Reliability
• 400,000 reads (calculated)
• Communication
  • Modem 2400 or 1200 bps; synchronous (SDLC) & asynchronous; 9600 bps optional
  • LAN
  • RS485 Hypercom LAN
  • PIN pad port
  • 2-wire or 4-wire, RS422
• Peripheral
  • S7C, S7SC, S8, P7E, ICE, HFT 105
  • Display
  • LCD: 2 lines x 20 characters
    Backlight
    25,000 hours (calculated)
• Environment
  • Temperature: 0-45 C/32-110 F
  • Humidity: Max 85%, non-condensing
  • ESD: 12,000 volts
• Footprint

  Height:	11.5 in	29.21 cm
  Width:	6.25 in		15.88 cm
  Depth:	4.5 in	11.43 cm
  Weight (Approximate):	1.98 lbs	0.74 kg

• Keypad
  • Silicone rubber
  • 35 keys
  • Reliability
  • 350,000 operations (calculated)
• Memory
  • RAM: Up to 1.0 MB
  • EPROM: 32 KB
  • RAM backup 5-year battery
• Power
  • AC: 85-250V, 50/60 Hz
  • DC: 24V, 1A
• Printer
  • Thermal Friction
  • Columns: 40 40
  • Paper width: 2.26 in/57.5 mm 2.26 in/57.5 mm
  • Paper type: Single-ply 1, 2 or 3-ply
  • Reliability: 5 million lines (calc.) 1.35 million lines (calc.)
• Product lifecycle
  • Reliability: 100,000 hours (calculated), not including printer
